Helios’ military field-grade UPS and power backup solutions

Our Military Field-Grade Uninterruptible Power Supply units are designed for the extreme environmental and demanding electrical conditions of Military/Aerospace applications.

This UPS will accept a wide range of input voltage and frequency values 80-265VAC; 47-65Hz while delivering a well-conditioned AC output to the load.

Up to three units can be combined to provide higher power, higher voltage and/or multiple output phases. The use of lithium polymer batteries permits the lowest profile and lowest weight solution in its power class. Options include a dual 500 W or single 2500 W DC output, a DC input rated for military 28 VDC sources, an electronic breaker on the AC output to permit fault-tolerant parallel operation for higher power and/or N+M redundant systems. Options include a DC output and the ability to also draw power from a military standard 28 Vdc input.

UPS Product Features

• Sealed, weather-proof, rugged UPS
• Shock-proof construction – outdoor UPS
• Military Tough, Die-Cast Aluminum Chassis
• 1250 W (1500 VA); 2500 W (3000 VA) output power
• >10 minute run-time at full power
• Full power operation -20°C to +55°C
• Shallow Rack full power operation -20°C to +50°C
• Storage temperature: -40°C to +65°C
• True on-line double conversion
• Hot swappable internal battery pack (lithium polymer)
• Universal AC input: 80-265 VAC; 47-65 Hz
• Dual input: AC and optional DC
• Cold-start with no AC or DC input connections
• Power factor correction at AC input
• Pure sinusoidal AC output voltage (115 VAC, 60 Hz)
• Handles 0.0 - 1.0 power factor loads and non-linear loads
• User I/O and Configuration signal ports
• Up to 3 units can be combined for higher power, voltage or a 3-phase AC output
• Up to 32 units can be combined to form a higher power fault-tolerant, glitch-free system, perhaps with N+M redundancy, by ordering with the “AC Output Electronic Breaker” option and the appropriate configuration cable

Specification Compliance

UPS units are designed to meet:

• MIL-STD-704 - Aircraft Electrical Power
• Mil-STD-1399-300 - Interface Shipboard
• MIL-STD-1275 - Vehicle Electrical Power
• MIL-STD-461 - Electromagnetic Interference
• MIL-STD-810 - Environmental Engineering

Options

• DC input (28Vnom) for dual source
• 2U Extended battery pack gives >24 minutes of run-time (UPS-1500)
• Wide-range AC input frequency: 47 Hz to 800 Hz
• 3-Phase Input
• 115 Vrms or 230 Vrms AC output
• 50 Hz, 60 Hz, or 400 Hz output
• DC1: Auxiliary isolated DC output (up to 500 W)
• DC2: High power DC output parallelable for higher power (UPS‑1500 up to 1250 W; UPS‑3000 up to 2500 W)
• Total AC and DC1 and DC2 output power UPS‑1500 = 1250 W
• Total AC and DC1 and DC2 output power UPS‑3000 = 2500 W
• Shipboard version with floating neutral wire
• N+1 Redundancy
• DC Input with full power DC Output

Increase your Backup Time with Expansion Battery Pack

SynQor’s Military-Grade UPS Expansion Battery (EBM) units are designed for the extreme environmental and demanding electrical conditions of Military Land, Shipboard, and Aerospace applications.

The expansion battery pack BAT-0400 series is a military-grade expansion battery pack that uses lithium polymer batteries and highly efficient power electronic circuitry to achieve a high power level and battery run-time in a low-profile, low-weight, rack-mountable package.  It can offer up to 13.5minutes run-time at full power (1250W).

For additional info about our Military Grade UPS please visit https://heliosps.com.au/product/military-field-grade-ac-ups-1kva-3kva
